MACHGRADE 2.0TFSI Upgraded Turbocharger is built using aluminum Custom Compressor Billet Wheel and Enlarged Turbine Wheel. These are based on the stock genuine KKK or IHI turbochargers and deliver the ultimate Plug&Play solution for Audi A3 8P/PA, Audi TT 8J, Seat Alhambra II, Seat Leon mk2, Skoda Octavia II, Volkswagen Golf VI, Volkswagen Golf V, Volkswagen Passat B6 with 2.0TFSI 200-211HP engines.
There are few versions available of the 2.0TFSI hybrid turbochargers with a peak power range of 300– 350 Crankshaft Horse Power, as follows:
MACHGRADE 2.0TFSI 300
Hybrid turbocharger ready to make ~300 Crankshaft Horse Power. Full list of changes applied:
- MACHGRADE custom journal bearings ‘360’,
- Modification of the compressor housing,
- Modification of the seal plate,
- Enlarged/custom compressor Billet Wheel 6+6 blades,
- Genuine Turbine Wheel clipped and lightened to help reduce the backpressure,
Further common features:
- Genuine compressor housing,
- Genuine exhaust manifold,
- Genuine bearing housing,
- Original actuator,
- Original DV,
- 100% Plug&Play installation,
- Dynamically Balanced.
MACHGRADE 2.0TFSI 330
Hybrid turbocharger ready to make ~330 Crankshaft Horse Power. The full list of changes applied is the same as with the 300 package with the exception of the Billet Compressor Wheel which is bigger and the Turbine Wheel which is also enlarged. This option is equipped with a reinforced genuine actuator as well.
MACHGRADE 2.0TFSI 350
Hybrid turbocharger ready to make ~350 Crankshaft Horse Power. The full list of changes applied is the same as with 330 package with the exception of even bigger both Billet Compressor Wheel and Turbine Wheel which is additionally lightened High-Flow 9 Blade in this case.
Performance Capabilities
To reach the declared level of power, you need to adjust your fuel, exhaust and cooling systems as well. Professional ECU remapping is required.
Engines
CCZA, CAWB, CCZB, BWA-BPY, AXX, BWA
OEM numbers
06J145722B
06J145722BX
06J145722BV
06J145713T
06J145713K
06J145702K
06J145701T
06J145701N
06F145701H
06F145701HX
06F145701HV
06F145701G
06F145701GX
06F145701GV
06F145701D
06F145701E
06F145701F
06F145701FX
06F145701FV
06F145701B
06F145701C
Cars
Audi A3 2.0 TFSI (8P) 200HP
Audi TT 2.0 TFSI (8J) 200HP
Seat Leon mk2 2.0 TFSI 200HP
Seat Toledo III 2.0 TFSI 200HP
Seat Alhambra II 2.0 TFSI 200HP
Skoda Octavia II 2.0 TFSI 200HP
Volkswagen Golf VI 2.0 GTI 211HP
Volkswagen Scirocco 2.0 TSI 200HP
Volkswagen Scirocco 2.0 TSI 211HP
Volkswagen Sharan II 2.0 TSI 200HP
Volkswagen Golf V 2.0 TFSI 200HP
Volkswagen Jetta V 2.0 TFSI 200HP
Volkswagen Passat B6 2.0 TSI 200HP
Factory numbers
9VA13
5303 988 0290
5303 988 0290
5303 988 0105
5303 970 0105
5303 988 0086
5303 970 0086
Before you order
- The average lead time (the time we need to build and ship a hybrid turbocharger) is 10 working days.
- In order to manufacture your turbo we require the following details of your car:
- model and year of build,
- stock power,
- VIN number
- Do you need a turbo with different specification? No problem! Learn more about hybrid turbo we can build
and contact us!
